CAMFLEX II 35-35212
The MASONEILAN CAMFLEX II 35-35212 Eccentric Plug Rotary Control Valve is a heavy duty automatic throttling control valve which incorporates the following features:-
- Flangeless body rating is a rugged ANSI Class 600.
- Heavy duty guide lugs assure quick, positive alignment during installation.
- Straight through flow pattern provides greater flow capacities.
- Standard integral extension bonnet allows for a wide range of fluid temperature application (-196°C to 400ºC)
- The unique self-aligning eccentric rotating plug provides tight shutoff and low dynamic forces.
- Differential Velocity Device (DVD) can be fitted into control valve for aerodynamic noise reduction which provides up to 18dBA noise attenuation.
- A large variety of reduced trim options available in sizes.
- Powerful, low profile spring diaphragm actuator guarantees positive “fail safe” action.
- Suitable for most process control application from temperature, pressure, level and flow control.
